Reef Factory Smart Tester

Product no.: 142357

Reef Factory Smart Tester - automatic measurement of one water value.

With the ability to schedule measurements and easily replace reagent cartridges, the Smart Tester makes monitoring aquarium parameters extremely simple. The device is designed so that calibration and cleaning are rarely automatic, which ensures unparalleled ease of use. From now on, you can not only automate the study of the selected parameter Ca, Mg, NO3, PO4, but also automate the maintenance of the selected parameter at a certain level by integrating Smart Tester actions with dosing pumps.

Reef Factory Smart Tester

Main Features:

Remotely controlled through the Smart Reef app.
Up to 160 tests on one reagent kit*.
Fully automated measurement
Quiet and precise operation due to proprietary dosing pumps
Quick replacement of the tested parameter through easy-to-install cartridges with reagents
Uses only 50 ml of water per measurement
Built-in self-calibration of the instrument
Compact size of 210x140x95 and modern design
Easy installation in the sump with DIN rail


Peristaltic pumps
The Smart Tester works on the basis of completely new peristaltic pumps developed by Reef Factory. Their design was developed to meet a number of requirements that equipment for marine aquaristics should fulfill. They are characterized by high dosing accuracy and the longest possible trouble-free operation, and are also very quiet.

Full automation
The Smart Tester performs the measurement completely independently, from water sampling to emptying the measuring cuvette and being fully ready for the next test. A one-time calibration of the instrument after installation does not require troublesome repetitions, as it has an auto calibration system for dosing pumps. This ensures the longest possible trouble-free operation and high dosing accuracy.

Reef Factory Smart Tester Connection

Modern device mounting system
To meet the needs of aquarists, we have improved the method of placing equipment in the cabinet. Reef Factory's latest instruments feature an innovative mounting system based on a DIN rail. This is an extremely practical and flexible solution that facilitates maintaining order in the cabinet.

To perform the measurement of the selected parameter with the Smart Tester, you need to purchase a set of special cartridges with reagents:


Mg - Magnesium measurement
Number of tests from one set: ~50 (depending on magnesium ion concentration)
Measuring range: 800-1800 ppm
Measuring resolution: 10 ppm
Test duration: ~40-60 min

PO4 - phosphate measurement
Number of tests from one set: 160
Measuring range: 0.00-3.00 ppm
Measuring resolution: 0.01 ppm
Test duration: ~40 min

The range of Smart Tester Reagents Pack cartridges will be gradually expanded with additional test sets for important parameters in aquaristics.

To use all the smart functions of the Reef Factory instruments, you need the free Smart Reef app, which you can install on your phone (Android, iOS) or operate via a browser.

Smart functions in the Smart Reef app:

Information about current reagent levels
Clear measurement history to compare changes in the aquarium.
Automation of processes with measurement plan and special actions.
Accurate water consumption counter
Option to perform a test outside the schedule
Notifications about upcoming replacement of the meter set and detected anomalies
Clear wizard to simplify the maintenance process for the measuring vessel
Water refill with automatic actions


TECHNICAL DATA
Dimensions and weight of the device: width 21 cm / 8.3 in height 14cm / 5.5 in depth 9.5 cm / 3.7 in

Technical data:
Power supply: 12V-1A Power consumption: 0.5-5W WiFi communication: 2.4 GHz Bluetooth communication: BLE 5.0 Water connection: 2x Luer-Lock Max. Water hose length 2m Operating temperature: 20-30°C Ambient humidity: 0 to 95% RH.
The device is CE certified

Scope of delivery:
Smart tester measuring device measuring tray with magnet tablet drop set with mounting tool
AC 110-230V power supply
DIN mounting rail
Water hoses 2x2m with connectors
Water filter with mounting system RO 50 ml
Container for rinsing the drip system

Additional mounting accessories and spare parts Reef Factory offers Smart Tester Reagents Pack for dedicated parameters.
