Abyzz AFC150IPU Compact - Abyzz Flow Cannon (90010169)

Product no.: 145744

Product description
The innovative Abyzz Flow Cannon AFC150 “compact” in high-end design, including a titanium rotor unit and titanium housing, consists of the pump itself and a powerful, programmable driver. With a highly energy-efficient motor, this product is an energy-saving solution in combination with the speed that can be adjusted to your performance requirements. The integrated bearing flush provides optimum protection against calcification and, in conjunction with the silicon carbide bearings and the special carbide shaft, ensures low-maintenance operation. All metal parts are made of grade 2 titanium and the remaining parts are made of high-quality plastics. This composition ensures a long service life, thus ensuring maximum sustainability and the lowest possible carbon footprint. Several mounting options are available for every requirement, and the many available mounting points make customer-specific mounting very easy. The special propeller design and well-designed hydraulics enable virtually noise- and vibration-free operation of the pump. The integrated flow rectifier ensures virtually laminar and powerful water movement. Simple programming (as with every Abyzz pump) and the option of connecting to external control systems offer a wide range of applications. The materials used are designed for a long service life and meet the highest requirements and quality standards. This product is developed and manufactured in Germany by venotec.

Special features
- Variable speed range (-70.0 – 100.0%)
- Operation possible in both directions of rotation
- Precise speed adjustment in 0.1% increments
- Integrated programming for generating waves, bursts, and random flow patterns with additional BOOSTMODE for overwriting the actual programming (MCFS – Menu Controlled Flow Sequencer)
- SELF – Safety extra-low voltage (12 V motor supply)
- Extensive safety functions such as dry run warning, temperature alarm, overcurrent protection, standstill warning
- Smooth start-up and dynamic control
- Auxiliary connection for peripheral devices (e.g., connection to external controllers)
- High-quality IP65 motor cable connector
- Low-noise operation
- Multicolor LC display with backlight
- Splash-proof driver (IP65)
- Wide-range input with active power factor correction
- Optimized heat sink design
- Dynamic control for natural water movement

Applications
- Freshwater and saltwater aquariums
- Gravity-fed pond filter systems
- Streams
- Water features
- Commercial applications

Technical data
Can only be operated submerged, minimum immersion depth 0.4 m (1.3 ft)

• Flow rate (max.): 60,000 l/h (264 gpm)
• Flow rate (nominal): 54,000 l/h (238 gpm)
• Max. flow velocity: 4 m/s (12 ft/s)
• Maximum force input (axial): 30 N
• Power consumption: 4...150 W
• Operating voltage: 100...240 V~
• Mains frequency: 50...60Hz
• Maximum immersion depth: 3m (10ft)
• Ambient temp. pump: +1…50°C (35…122°F)
• Ambient temp. driver: +1…30°C (35…86°F) (without additional cooling)
• Pump cable length (optional): 4/7m (13/22ft)

Scope of delivery
- Abyzz AFC150 pump, 4 or 7m cable
- Abyzz AFC150 IPU driver incl. power cable (1.5m)
- Info card with link to instructions
- Registration documents

Mounting
The integrated mounting option consists of three screw holes arranged in a star shape on the back of the pump. Additional mounting options such as magnets and clamps are available separately and can be found on our website or in our catalog.
